Skydance 2 Technical Information

Note: Dimensions include footplates (protrude 70mm on each side)

PDF:  Foundation Plans
          Snow Load & Wind Load
          Weight Calculation



The height is calculated with the louver roof in the open position (max. height).

Details



Snow Load & Wind Load

Model Snow load (kg/m2) Wind load (Beaufort scale)

3x3m

150 11
3x4m 150 11
4x4m 150 11
4x6m 120 11



The wind and snow load information pertains to the assembly and fastening on point foundations measuring 85 cm x 85 cm x 85 cm per column, using anchor bolts that are at least 140 mm long.
